Hydraulic Multi-Cylinder Cone Crusher is world advanced level cone crusher, based on years of experience and world advanced technology, which can be widely used on metallurgy, construction, hydro-electric, transportation, chemical and construction material etc. It is always used to crush stones or ores of medium and high hardness. Compared with similar equipment, it has the advantages of reasonable structure, reliable performance, safe operation and convenient maintenance etc. Adopting hydraulic driving structure, our hydraulic multi-cylinder cone crusher can adjust discharge port quickly to balance production and get best production rate by adjusting crushing circuit. There are several in order to get different output size. The hydraulic system is convenient and reliable with safe and effective overload protection. The hydraulic adjustment and hydraulic cavity cleaning increase automatic degree and decrease or even avoid downtime, by which both manual power and production cost have been reduced greatly. Experience and practice has proved that H series Hydraulic Multi-Cylinder Cone Crusher has good performance in intermediate crushing, fine crushing or super fine crushing.
Model& specification | Specification | Cavity type | Size of feed port(mm) | Minimum discharge open(mm) | Main motor power(kw) | Discharge outlet size(mm) | Capacity (t/h) | ||
Opening side | Closing side | ||||||||
PYH-D1306 | H200 | shorthead | Fine | 64 | 29 | 5 | 155
| 5-16 | 55-170 |
PYH-D1308 | intermediate | 89 | 54 | 6 | 6-16 | 80-170 | |||
PYH-D1310 | Rough | 105 | 70 | 10 | 10-25 | 106-225 | |||
PYH-D1313 | Extrarough | 133 | 98 | 19 | 19-25 | 190-237 | |||
PYH-B1313 | Standard
| Fine | 137 | 109 | 13 | 13-31 | 115-190 | ||
PYH-B1321 | intermediate | 210 | 188 | 16 | 16-38 | 137-265 | |||
PYH-B1324 | Rough | 241 | 216 | 19 | 19-51 | 180-366 | |||
PYH-B1325 | Extrarough | 259 | 238 | 25 | 25-51 | 245-380 | |||
PYH-D1607 | H400 | shorthead | Fine | 70 | 35 | 6 | 240 | 6-13 | 110-220 |
PYH-D1608 | intermediate | 89 | 54 | 6 | 6-19 | 145-325 | |||
PYH-D1613 | Rough | 133 | 98 | 10 | 10-25 | 200-353 | |||
PYH-D1614 | Extrarough | 158 | 117 | 13 | 13-25 | 265-353 | |||
PYH-B1620 | Standard
| Fine | 209 | 188 | 16 | 16-38 | 190-345 | ||
PYH-B1624 | intermediate | 241 | 212 | 22 | 22-51 | 270-438 | |||
PYH-B1626 | Rough | 269 | 241 | 25 | 25-64 | 315-660 | |||
PYH-B1636 | Extrarough | 368 | 331 | 38 | 38-64 | 450-660 | |||
PHY-DC2110 | H600 | shorthead | Fine | 105 | 51 | 6 | 400/450 | 6-16 | 315-475 |
PHY-DC2113 | intermediate | 133 | 95 | 10 | 10-19 | 410-590 | |||
PHY-DC2117 | Rough | 178 | 127 | 13 | 13-25 | 525-695 | |||
PHY-DC2120 | Extrarough | 203 | 152 | 16 | 16-25 | 588-756 | |||
PHY-BC2127 | Standard
| Fine | 278 | 253 | 19 | 19-38 | 565-840 | ||
PHY-BC2133 | intermediate | 334 | 303 | 25 | 25-51 | 705-1160 | |||
PHY-BC2136 | Rough | 369 | 334 | 31 | 31-64 | 910-1450 | |||
PHY-BC2146 | Extrarough | 460 | 425 | 38 | 38-64 | 1000-1550 | |||
PHY-D2512 | H900 | shorthead | Fine | 120 | 60 | 10 | 630 | 10-16 | 560-6700 |
PHY-D2515 | intermediate | 150 | 100 | 13 | 13-19 | 670-810 | |||
PHY-D2519 | Rough | 190 | 130 | 16 | 16-22 | 770-1000 | |||
PHY-D2522 | Extrarough | 220 | 160 | 19 | 19-25 | 920-1190 | |||
PYH-B2530 | Standard
| Fine | 300 | 275 | 19 | 19-38 | 700-1200 | ||
PYH-B2535 | intermediate | 350 | 320 | 25 | 25-51 | 1050-1900 | |||
PYH-B2541 | Rough | 410 | 375 | 31 | 31-64 | 1300-2500 | |||
PYH-B2548 | Extrarough | 480 | 445 | 38 | 38-64 | 1500-2600 |
